Product Details
| Property | Value |
|---|---|
| Guides | Extruded aluminum channels with continuous wear strips |
| EES Emergency Egress | The Wayne Dalton emergency egress grille provides secure access to public areas yet will automatically open fully upon detection of an alarm or power failure. This prevents entrapment in the event of an emergency and allows immediate access to emergency personnel. (Available on motor-operated doors) |
| Design Options | Acrylic Lites, Steel mountain tubes, End covers |
| Bottom Edge Options | Astragal, Pneumatic, Electric sensing edge |
| Colors - Anodized Aluminum Finishes | Clear, Bronze |
| Hood | Square hood and brackets, 24-gauge galvanized steel, Stainless steel, 20-gauge B&S aluminum |
| Brackets | Aluminum square hood |
| Bottom Bar | Steel barrel; housing spring assembly |
| Barrel | Steel plates |
| Colors - Steel Finishes | Galvanized Steel, Stainless Steel |
| Colors - Guides/Brackets/Barrel/Bottom Bar/Guides Finish | Clear Anodized Aluminum, Bronze Anodized Aluminum, Mill Aluminum, Galvanized, Stainless Steel |
| RAL Powder Coat | Approximately 200 powder coat options are available to complement the exterior colors of a building. |
| Operation | Manual Push-up - Awning crank, Wall crank, Chain hois,t Motor Motor with chain |
| Mounting | Face-of-wall or between jambs |
| Max. Width | 20' |
| Max. Height | 14' |
| Material | Aluminum |
| Locking Options | Cylinder lock, Best lock, Slide bolts, Thumb turns, E-Z LOK (EES only) |
| Ideal Applications | Retail, Parking Garages, Schools, Hospitals, Office buildings, Airports, Banks, Pharmacies |
| Grille Pattern | Compact aluminum with vinyl bulb seal |
| Door Type | Grilles |
| Design Solutions | High Cycle Springs, Super-imposed combination doors, Curb cut out bottom bars, Combination door mounts, Sloped bottom bars |
| Curtain Pattern | Steel barrel; housing spring assembly |
| Curtain | Interlocking extruded aluminum slats constructed of .05" aluminum |
| Property | Value |
|---|---|
| Application -Multi-Family Housing | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-multi-family-housing.pdf |
| Application - Retail Automotive | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-retail-automotive.pdf |
| Wayne Dalton High Cycle Springless Grill Introduction | https://www.wayne-dalton.com/docs/default-source/press-releases/2019/pr-model-600-hc.pdf |
| Rolling Grill Patterns | https://www.wayne-dalton.com/docs/default-source/grille-patterns/rolling-grille-patterns-model-600.pdf |
| Application - Retail Storefront Security Solutions | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-retail-storefront-security.pdf |
| Application - Public Government Facility | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-public-government-facility.pdf |
| Application - Healthcare & Pharmaceutical | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-healthcare-pharmaceutical.pdf |
| Installation Instructions | https://www.wayne-dalton.com/docs/default-source/install/comm/grilles/model-600-installation.pdf |
| Rolling Door Systems Brochure | https://www.wayne-dalton.com/docs/default-source/brochure/comm-counters/rolling-door-systems-brochure.pdf5 |
| Owners Manual | https://www.wayne-dalton.com/docs/default-source/owners-manual/rolling-door-end-user-manual.pdf |
| Model Brochure | https://www.wayne-dalton.com/docs/default-source/brochure/comm-grilles/security-grilles-model-600-brochure.pdf?sfvrsn=fa3b6513_5 |
| EES Warranty | https://www.wayne-dalton.com/docs/default-source/warranty/comm-rolling/model-600-600ees-warranty.pdf |
| Door Operating Clearance | https://www.wayne-dalton.com/docs/default-source/door-operating-clearance/door-operating-clearance-model-600.pdf?sfvrsn=3a82a1a8_5 |
Product Resource download links.
