Product Details
| Property | Value |
|---|---|
| High Cycle Spring Options | 25,000, 50,000, 100,000 |
| Lite Options | Vision, Contemporary, Colonial, Ranch, Sonoma, , Stucco-Embossed Pinstripe |
| Operation | Chain hoist operation, Motor operation |
| Safety Focused | Cable failure device, Sensing edges, Photo eyesCable failure device, Sensing edges, Photo eyes |
| Max. Width | 26'2" |
| Max. Height | 20'1" |
| Color - Stucco Options | White Stucco, Almond Stucco, Taupe Stucco, Brown Stucco |
| Spring Cycle | 10,000 |
| Sound Transmission (STC- ASTM E 413) | Class 20 |
| Sectional Thickness | 1 7/8" 3 layer" |
| U-factor | 0.12 |
| Thermal Break | Yes |
| Wind Load (optional) | No |
| Design Options | Jamb seal, Mullions, 3” Track |
| R-value | 16.22 |
| Impact Panel Option | The Wayne Dalton Impact Section replaces the traditional bottom section on doors exposed to damage from forklifts and other warehouse traffic. Available for 21" and 24" sections or from 8’2” to 16’2” wide in one-foot increments, this fully adaptable design provides a superior fit, reduces downtime, costly repairs and has impact-resistant composite skin that surrounds an expanding polystyrene core. |
| Ideal Applications | Manufacturing Plants, Production Facilities, Loading Docks, Storage Facilities, Commercial Buildings, Industrial Facilities, Drive-Thru Bays, Truck Bays, Vehicular Storage |
| Exterior Surface | Stucco Embossed / Flush |
| Door Type | Insulated Sectional Steel |
| Air infiltration (IECC) | 0.17 cfm/ft2at 15 mph |
| Property | Value |
|---|---|
| Installation Insert - Commercial Sectional Low Headroom | https://www.wayne-dalton.com/docs/default-source/instuction-inserts/commercial-sectional-low-headroom-installation-insert-360564-insert.pdf |
| Installation Instructions ThermoMark™ Wind Load Model | https://www.wayne-dalton.com/docs/default-source/install/comm/sectional/5150-5155-5200-5255-starndard-lift-windload-353363.pdf |
| Track Selection Guide Sectional Steel Doors | https://www.wayne-dalton.com/docs/default-source/panel-section-guide/track-selection-guide-sectional-steel-doors.pdf |
| Cable Keepers Installation Insert | https://www.wayne-dalton.com/docs/default-source/instuction-inserts/cable-keepers/cable-keeper-insert.pdf |
| Installation Instructions | https://www.wayne-dalton.com/docs/default-source/install/comm/sectional/5150-5155-5200-5255-standard-lift-353361.pdf |
| Door Panel Section Guide | https://www.wayne-dalton.com/docs/default-source/panel-section-guide/door-panel-sectionguide-model-5155-5255.pdf |
| Model Brochure | https://www.wayne-dalton.com/docs/default-source/brochure/commercial/sectional-insulated/sectional-steel-door-model-5155-5255-brochure.pdf |
| Quick Start Guide - Wind Load | https://www.wayne-dalton.com/docs/default-source/quick-start-guides/comm-insulated-steel/thermomark-5150-5155-5200-5255-windload-qsg-353364.pdf |
| Quick Start Guide | https://www.wayne-dalton.com/docs/default-source/quick-start-guides/comm-insulated-steel/sectional-door-thermomark-series-torsion-standard-lift-qsg-353362.pdf |
| Operating Clearance Commercial Sectional | https://www.wayne-dalton.com/docs/default-source/door-operating-clearance/commercial-sectional-general-operating-clearances.pdf |
| Sectional Steel Door Impact Section Option Flyer | https://www.wayne-dalton.com/docs/default-source/brochure/comm-sectional/sectional-steel-door-impact-section-option-flyer.pdf |
| Sectional Door Systems Brochure | https://www.wayne-dalton.com/docs/default-source/brochure/commercial/comm-sectional/sectional-door-systems-brochure.pdf |
| Thermospan® Insulated Door Operator System Warranty | https://www.wayne-dalton.com/docs/default-source/warranty/comm-rolling/thermospan-insulated-sectional-steel-door-warranty.pdf |
| Application - Cold Storage - Food & Beverage | https://www.wayne-dalton.com/docs/default-source/applications/commercial-applications-cold-storage-food-beverage-applications-brochure.pdf |
