| Curtain Gauge Options | 20 or 18-gauge Steel front, 22, 20, or 18-gauge Stainless steel front |
| Curtain | Interlocking roll-formed slats with alternate slats fitted with metal end-locks/ wind-locks |
| Counterbalance | Helical springs, oil tempered, iron barrel plugs for anchoring springs to shaft and pipe; 20,000 cycle |
| Sensing Edge Options | Electrical, Pneumatic |
| Release Mechanism | Yes |
| RAL Powder Coat | Approximately 200 powder coat options are available to complement the exterior colors of a building. |
| Door Type | Fire Doors |
| Signal Device Options | Fire Release Device ,Horns and Strobes, Smoke Detectors |
| Perimeter Seal Options | Angled guide brush seal, Exterior lintel weather, Flame baffle, Smoke package - Full perimeter seal, Caulking, Label |
| Colors | White, Gray, Beige, Brown |
| Max. Sq. Footage | 324 sq. ft. |
| Max. Height | 24' |
| Material | Galvanized or Stainless Steel |
| Locking Options | Slide bolts, Cylinder, Best lock, Thumb turns |
| Wind Lock Options | Alternating or continuous with windbar Florida Building Commission Impact Rating – Certified for Florida's High Velocity Hurricane Zone (Up to +/- 55 psf) |
| Vision Options | FireLite*- 5" x 3/4", FireLite* fenestration with glass vision lite, 6" curved slat |
| Steel Gauge | 18 |
| Operation | Lift-up, Manual Crank, Motor operation, Chain hoist |
| Mounting | Structural steel, drywall over wood stud jamb, drywall over 16-gauge steel stud jamb |
| Max. Width | 24' |
| Ideal Applications | Distribution Centers, Food Service Areas, Stadium Concessions, Service Stations, Storage Areas, Warehouses, Manufacturing, Trucking Distribution Center |
| Hood | 22-gauge steel, Square hood |
| Brackets | 3/16" or 1/4" steel plates with sealed ball bearings, painted factory black |
| Bottom Edge Options | Astragal, Pneumatic, Electric sensing |
| Bottom Bar Options | Stainless steel double angle, Galvanized structural steel angle construction, Sloped |
| Bottom Bar | Two equal angles Thickness- 0.121" min to stiffen curtain |
